Pressure Sensors

Pressure Sensors

Accurate Pressure Monitoring for Industrial, Process & Testing Applications
Proact IMS offers a comprehensive range of pressure sensors and transducers designed for real-time monitoring of gases, liquids, and hydraulic systems. Engineered for high accuracy, stability, and ruggedness, our pressure sensors are ideal for both static and dynamic measurement in demanding environments.
Available in strain gauge, piezoresistive, and capacitive technologies, our sensors cover a wide pressure range—from vacuum to ultra-high pressure—and support analog, digital, and wireless outputs.

Types of Pressure Sensors Available

• Strain Gauge Pressure Transducers
• Highly accurate with low thermal drift
• Suitable for industrial process systems, hydraulics, and material testing rigs

Piezoresistive Pressure Sensors

• Ideal for dynamic and transient pressure applications
• Used in automotive engine monitoring, combustion analysis, and flow systems

Differential Pressure Sensors

• Measure pressure difference across filters, valves, or chambers
• Widely used in HVAC, cleanrooms, and flow metering setups

Absolute Pressure Sensors

• Reference pressure measured against a vacuum
• Common in aerospace, barometric measurements, and altimetry

Gauge Pressure Sensors

• Measures pressure relative to ambient atmosphere
• Used in tanks, vessels, pumps, and industrial processes

Flush Diaphragm Sensors

• Suitable for viscous or clog-prone media
• Used in food processing, petrochemical, and wastewater plants

• Technical Specifications
  • Pressure range: ±10 mbar to 1000 bar
  • Accuracy: up to ±0.1% FS
  • Output: 4–20 mA, 0–10V, RS-485, Modbus, CANopen
  • Materials: stainless steel, Inconel, ceramic diaphragm
  • Process connections: BSP, NPT, flanged, custom fittings
  • Temperature range: –40°C to +150°C (sensor dependent)
• Applications

  Industrial Automation & Process Plants

  • Boiler pressure monitoring, pipeline pressure control, pressure-relief systems

  Oil & Gas Operations

  • Wellhead pressure, manifold monitoring, and refinery process control

  Automotive & Aerospace Testing

  • Intake manifold pressure (MAP), combustion chamber, fuel rail pressure

  R&D Labs & Test Benches

  • Pressure mapping during mechanical testing, material strength studies

  Water Treatment & Utilities

  • Flow regulation, pump monitoring, and pipe integrity systems
• System Integration
  • Compatible with SCADA, PLC, NI DAQ, LabVIEW, and IoT platforms
  • Can be paired with load cells, strain gauges, temperature sensors, and DAQ software
  • Wireless telemetry modules available for remote or hazardous locations
  • Calibration services with traceable certificates included

Why Choose Proact IMS Pressure Sensors?

• Wide range of models to match any media, range, or environment
• Reliable under vibration, overpressure, and thermal cycling
• Custom-engineered sensor packages for OEMs and lab setups
• In-stock availability for standard ranges; fast turnaround for custom units
• Global delivery and expert support from selection to commissioning
