Inclinometer accessories

ABS resin guide pipe
KBF-51-2:2m

Guide Pipe Socket KBF-32/KBF-22/KBF-52/IM-GP-SA

These pipes Socket are used to connect guide pipes.
Aluminium Pipe Socket
KBF-32
KBF-22
IM-GP-SA

ABS resin guide pipe Socket
KBF-52

Aluminium Guide Pipe Cap

These caps are used to prevent muddy water from entering the Aluminium guide pipes. (Cap available for both top and booottom.)
KBF-34
KBF-24
IM-GP-CA

ABS resin cap for guide pipe

Prevents muddy water from entering the ABS resin guide pipe.
Head cap
KBF-54-1

Bottom cap
KBF-54-2

Rod End

KBF-36-1  Used to fix the uppermost part of a multistage inclinometer (KB-JG/KB-KG/KB-KD)
KBF-26-1  Used to fix the uppermost part of a multistage inclinometer (KB-JH／KB-KH)
KBF-36-3  Used to fix the uppermost part of a multistage inclinometer (NKB-LF/NKB-MF)
IM-RE  Used to fix the uppermost part of a multistage inclinometer (IM-UA/IM-BA)

Cable Holder KBF-37

When measuring with an insertion-type inclinometer (KB-GC/KB-HC), the cable is held at the measurement position.

Rivet KBF-38/KBF-28

• KBF-38  Rivet for fixing guide tubes (KBF-31) and guide tube sockets (KBF-32)
                Rivet for fixing guide tubes (IM-GP) and sockets (IM-GP-SA)
• KBF-28  Rivet for fixing guide tubes (KBF-21) and guide tube sockets (KBF-22)

Riveter KBF-39(HR002D)

This Rivet is a pair of pliers used to mount KBF-38(HR002D) Rivets.

Suspension Fitting KBF-39-2

Auxiliary fittings for installing multi-stage inclinometers

Storage Trunk KBF-60

Storage trunk for the main unit for insertion-type inclinometers (KB-GC/KB-HC)

Removal Plier KBF-39-1

This Pliers are used to remove Relay Rods and Extension Rods from Inclinometers.

Relay Rod

This rods are used to connect Multi-layer Inclinometers on multiple levels.

Extension Rod KBF-33L

The KBF-33 Rods are used to extend Relay Rods.
