SDP-E Displacement Transducer 50 to 300mm

This is a strain gauge type displacement transducer for general purpose. This transducer has a small cantilever inside, and displacement is mechanically converted into deflection of the cantilever. Strain, which is proportional to the deflection, is generated on the cantilever and is measured by strain gauges.

Stable measurement is possible even for a small displacement. The scale and pointer on the main body enables easy positioning of the transducer.

For SDP-200E and SDP-300E, a dual-output type with two independent input/output ports is optionally available.

• Protection ratings : IP 40 equivalent

• Features
  • Excellent Stability
  • Easy handling
  • Convenient visual scale
